Merida (Taiwan) - Press Release: The New eOne-Twenty eMTB from Merida.

eOne-Twenty Merida Features:

Prolite 66 Triple Butted Aluminum:

Our proven high-end aluminium (6066) is extremely light and durable. Using triple butted wall thicknesses and hydroforming technology, we can tune the aluminium tubes to give the best possible stiffness to weight ratio.

X-Taper Headtube:

Using a tapered head tube with 1 1/8" bearings in the top and 1 1/4" or 1 1/2" in the bottom creates superb stiffness and precise, confidence inspiring steering.

Smooth Welding:

Sometimes called ‘double pass welding’, a second pass over the weld gives a clean organic look to the frame. At first glance, you will be convinced it is carbon.

Internal Cable:

Cables are routed through the frame, entering and exiting through smooth sockets. The bike looks neat, whilst the cables are protected from moisture and dirt.

Smart Entry:

Cables, housings and brake hoses are clamped under tension to prevent rattling when the trails or roads get rough. All inlets are completely interchangeable to deal with Di2, hydraulic hoses, brake cable and gear cable housings etc.

DI2 Ready:

Bikes/frames with the symbol ‘Di2 Ready’ are prepared for the installation of Di2 technology with battery mounting in the seat post or within the fork steerer.

12-148 Thru-Axle ‘Boost’:

New Boost standard – wider axle widths; 110 mm front and 148 mm rear, allowing a shallower spoke angle for stiffer wheels, especially beneficial in 29ers.

C-S Post Mount Disc:

Post mount disc brake calipers fit directly onto the seat stay for a strong and light connection whilst a chainstay post mount positions the caliper on the chainstay within the rear triangle for extra protection and better distribution of braking forces. Another benefit is that internal cable routing is also easier and neater via the chainstay.

Casting Motor Bracket:

Sophisticated shape only possible due to casting technology, creating an integrated appearance as well as an extremely strong connection between the E-bike motor and frame for improved performance and reliability.

HFS - Hydro Forming System:

Tubes are inserted into negative moulds and a hot emulsion of water and oil is forced through at pressure, enabling them to be formed into complex shapes.

15-110 Thru-Axle ‘Boost’:

New Boost standard – wider axle widths; 110 mm front and 148 mm rear, allowing a shallower spoke angle for stiffer wheels, especially beneficial in 29ers.

Specifications:

  • Frame Sizes: S, M, L, XL
  • Frame: eOne-Twenty
  • Fork: Rock Shox Pike RC, Air, 130mm suspension travel, Tapered
  • Shock: Rock Shox Deluxe RT, platform
  • Derailleur Front: no
  • Derailleur Rear: SRAM RD NX Eagle Rear Derailleur
  • Shifters: no / SL GX Eagle Single Click Trigger
  • Brake Lever: attached
  • Brakes: Sram Code R
  • Chainwheel: SRAM X-SYNC Eagle, 34 teeth
  • Chainguard: Shimano SM-CDE80
  • Chain: Sram NX Eagle
  • Rim: Fulcrum E- Fire 500, 110x15mm width front hub, 148x12mm width rear hub, 35mm inner width, 6 bolt
  • Freewheel: Sram NX 1230 Eagle, 11-50 teeth, 12 speed
  • Tires: Maxxis DHR II, 27.5x2.8 ", fold, 3C EXO TR
  • Spokes: attached
  • Handlebar Stem: Merida Expert eTR, 35mm diameter, 0° stem angle
  • Handlebar: Merida Expert eTR, 780mm width, 20mm rise
  • Headset: FSA NO.55EP neck, 2191017484
  • Seat Post: Merida Expert TR, 30.9mm diameter, 0 SB, S: 100mm travel seatpost - M/L/XL 125mm travel seatpost,
  • Saddle: Merida Expert CC
  • Pedal: VP, VPE-537
  • Battery: Shimano E8010, 504 Wh
  • Display: Shimano SC-E8000
  • Motor: Shimano E8000, 70Nm
  • Weight: 22.21 kg



Other Models:

  • eOne-Twenty 900E
  • eOne-Twenty 800
  • eOne-Twenty 600
  • eOne-Twenty 500
