New BMX Eastern Shovelhead 2019

New BMX Eastern Shovelhead 2019

Eastern Bikes (United States) - The expert level Eastern Shovelhead has been an Eastern staple for over a decade. A full chromoly frame, fork and bars provide lightweight performance. The Shovelhead is finished off with fully sealed hubs, 3-piece 48 Spline cranks, Squealer 100psi tires, alloy sprocket, double wall rims and our new Facet pedals (2 Steel Pegs Included).

  • 25.6 Lbs
  • Chromoly Frame
  • Chromoly Fork
  • Chromoly Bars
  • Sealed Hubs
  • 3 Piece 48 Spline Cranks
  • Mid BB
  • Integrated Headset
  • Eastern Grips
  • Alloy Eastern Phorcys Sprocket
  • Pivotal Seat
  • Double Wall Front and Rear Rims
  • 2.4" Eastern Squealer 100psi Tires
  • Eastern Facet Pedals
  • 2 Cold Steel Pegs



  • Full Chromoly Shovelhead 20", Removable Brake Mounts
  • Top Tube Size: 21.0″
  • BB: Mid
  • Headtube: Integrated
  • Chainstay Length: 13.38″
  • Clamp: Integrated with Frame



  • Full Chromoly 9.0"
  • Upsweep/Backsweep 12⁰/1⁰



  • Full Chromoly, Tapered Legs, 3/8" Dropouts
  • Fork Rake: 28mm


Other Components:

  • Headset Integrated 45°X45° Sealed Cartridge Bearing
  • Stem CNC Machined 6061 Missile Grade Aluminum Top Load Stem
  • Grip Eastern Riblet Grips
  • Crank 3-Piece, Tubular Heat-Treated Chromoly, 48-Splined Spindle, 170mm Arm Length
  • Bottom Bracket Sealed Bearing Mid
  • Chainwheel Eastern Phorcys, Alloy, 28T
  • Chain KMC Z510 1/2 x 1/8
  • Pedal Eastern Facet Pedal with 9/16" Chromoly Axle
  • Front Brake N/A
  • Front Lever N/A
  • Rear Brake U-Brake, Forged Alloy, Wide Body, Clear Brake Pads
  • Rear Lever Forged Alloy Lever
  • Brake Cable [S] Linear
  • Saddle Medium Width Pivotal Seat
  • Post Pivotal, Forged Alloy, 200mm
  • Front Hub Sealed Bearing, Forged Alloy Shell, Drilled for 36 Spokes, Female Axle System with 3/8" Allen Key Bolts
  • Rear Hub Sealed Bearings, Forged Alloy Shell Drilled for 36 Spokes, 14mm Chromoly Axle
  • Freewheel 9 Tooth Driver with Hub
  • Front Rim Alloy, Double Wall, Drilled for 36 Spokes. For 20″ Tires
  • Rear Rim Alloy, Double Wall, Drilled for 36 Spokes. For 20″ Tires
  • Spokes 14 Gauge with Brass Nipples
  • Front Tire Eastern Squealer 100psi 20 x 2.40
  • Rear Tire Eastern Squealer 100psi 20 x 2.40
  • Peg Cold Steel Pegs (2pcs)
