Chase Bicycles (United States) - Press Release: We don't ever settle for good enough.
The Chase Edge has been one of the most sought after completes in BMX racing for the past few years. We don’t settle for good enough at Chase, so we decided to make our top selling bike even better. For 2019, we started out with the heart of the Edge, the frame, where we upgraded it with a new Triple butted Premium Ultralight Alloy Hydroformed tubed frame on the entire size range. We also changed the head tube, adding to the list of upgrades on the Frame.
The Edge has some of the best parts on a complete BMX race bike, including a new Chase rear cassette hub, a Tioga Tires, Tektro brake set, Insight chainring, grips, chain tensioners, KMC Chain, and a Pivotal seat / seat post, all help round out the Edge to make it one of the most dialed in complete bikes in BMX.
The Chase Edge is offered in 8 different sizes, giving you the perfect size bike for just about any BMX racers needs. Edge out the competition on and off the track with the new 2019 Chase Edge complete race bike!
Expert XL Specifications:
- Frame: Chase Edge Expert XL 20″ Top Tube 6061 T6 Alloy Triple Butted Hydroformed, Integrated Head Tube, 1-1/8″, Water Decals
- Fork: Chase Edge Full Cr-mo, 1-1/8″ Steer Tube With Tapered Blades
- Headset: Integrated Sealed Bearing
- Handlebar: Chase Edge Bar 6.5″ Rise, 8° Back Sweep & 2° Up Sweep
- Grips: Insight C.O.G.S 130mm Alloy Clamps Laser Etched Logo, PVC End Plug
- Stem: Chase Edge 50mm 6061 T6 Alloy Laser Etched Logo
- BB: 113mm Sealed Cartridge Isis BB
- Chainring: Insight 42 Tooth 4 Bolts 104mm 1/2″x3/32″ 5mm Alloy Ring
- Crank: Chase Edge 3 Piece Crank 170mm Alloy Arm With Laser Etched Logo, Cr-mo Chain Ring Bolts / Nuts
- Pedal: Platform Pedal 9/16″
- Chain: KMC Z33 1/2″x3/32″
- Cog: 16 Tooth
- Front Hub: Mini Hub, 32H, Double Contact Seals Bearing with Dust Caps, 3/8″ Axle/Nuts
- Rear Hub: 32H, Sealed Cartridge Bearings with Dust Caps, 3/8″ Axle/Nuts, Steel Cassette Body, 4 Pawls, 96 Points Of Engagement
- Spokes: 14 Gauge
- Nipples: Brass Nipples
- Front Rim: Chase Edge 150 Double Wall 32H 20″x1.50″ Schrader Valve
- Rear Rim: Chase Edge 150 Double Wall 32H 20″x1.50″ Schrader Valve
- Front Tire: Tioga PowerBlock 20″x1.60″
- Rear Tire: Tioga PowerBlock 20″x1.40″
- Tubes: 20”x1.50″-1.75″ Schrader Valve
- Brake Lever: Tektro ML330
- Brake Caliper: Tektro 836AL
- Saddle: Pro Pivotal
- Seat Post: Pivotal 27.2x250mm Polished Alloy
- Seat Clamp: Chase Edge QR Alloy 31.8mm
- Chain Tensionner: Insight Twin Hole Laser Etched Logo
Other Models:
- Micro 18″
- Mini
- Junior
- Expert
- Pro
- Pro XL
- Cruiser
