Cannondale (United States) - Press Release: A surprisingly agile mountain bike for enduro racing and all-mountain competitions.

Spot-On Geometry:

The Jekyll 29 offers the incredible stability you'd expect from a big 29er, with the add benefit of boosted agility and snap from the ultra-short chainstays of our Ai rear end: 65° head tube angle, Designed for short stems and wide bars for optimum control, Long front-center, Super short chainstays (442 mm), thanks to the Ai offset drivetrain, Steep seat angle facilitates efficient pedaling.

Leveraged Single-Pivot Design:

The system's leverage rations can be customized for optimal suspension response throughout the spoke, thanks to an efficient link between the swingarm and the shock. This also keeps the suspension active when you brake, without sacrificing the stiffness, durability, and reliability of a traditional single-pivot design.

Perfect MTB Precision:

With BallisTec Carbon construction, the stout Ai rear end and LockR pivots holding everything tightly together, the Jekyll 29 boasts incredible chassis stiffness for precise control and explosive acceleration.

Jekyll 29 -1- Specifications:

• Frame: All-New Jekyll 29", 150mm travel, BallisTec Carbon front triangle, SmartForm C1 Alloy swingarm, Ai offset drivetrain, ISCG05, PF30, flat mount brake, tapered headtube
• Fork: Fox Float Factory 36, 150mm, FIT Grip2 Damper, Kashima coating, 15x110, tapered steerer, 42mm offset
• Rear Shock: Fox Float Factory DPX2 Evol w/ Gemini dual mode air spring system (Flow Mode - 150mm / Hustle Mode - 120mm), remote-actuated, 3-Pos adj.
• Rims: Stan's NoTubes Flow MK3, 32h, tubeless ready
• Hubs: Sram 900 15x110 front, SRAM 900 12x148 rear w/ XD driver
• Spokes: DT Swiss Competition (Ai Offset dish - rear)
• Tires: Maxxis Minion DHF 29 x 2.5" WT front, DHR II 2.4" WT rear, 3C Compound, Max Exo puncture protection, tubeless ready
• Pedals: Not Included
• Crank: Truvativ Stylo 7K, 30T, Ai Custom
• Bottom Bracket: Cannondale Alloy PressFit30
• Chain: Sram X01 Eagle, 12-speed
• Rear Cogs: Sram XG-1295, X01 Eagle, 10-50, 12-speed
• Rear Derailleur: Sram X01 Eagle
• Shifters: Sram X01 Eagle, 12-speed
• Handlebar: Cannondale C1 Riser, Carbon, 15mm rise, 9° sweep, 4° rise, 780mm
• Grips: Cannondale Locking Grips
• Stem: Cannondale C1, 3D Forged 6061 Alloy, 1-1/8", 31.8, 0°, 35mm
• Headset: Integrated, 1-1/8 to 1.5", sealed angular contact bearings
• Brakes: Sram Code RSC hydro disc, 200/180mm Centerline rotors
• Brake Levers: Sram Code RSC hydro disc
• Saddle: Fabric Scoop Shallow Elite, cro-mo rails
• Seatpost: Fox Transfer dropper, Kashima coating, internal routing, 31.6, 125mm (S), 150mm (M-XL)
• Sizes: S, M, L, XL

Other Models:

• Jekyll 29 -2-
• Jekyll 29 -3-
