Lynskey Performance Designs (United States) - A beast in the grit and a thoroughbred on the road. This bike doesn’t break ground it destroys it — the first and still the only Hand-Built Gravel frame with a 6AL/4V Aerospace Grade Titanium Tubeset!
Who is this bike for:
Power focused riders who need a rig that can handle the toughest conditions on any day, but demand a titanium comfort ride with a smooth finish.
What it is:
A gravel bike that possesses the power transfer, stiffness, and precision-handling capabilities — traditionally only found in our top tier Pro Level Performance road bikes. The bike you want on those on bone-rattling rides, when the carbon crowd gets nervous. Lynskey’s signature tube within a tube cable routing system flows smoothly into the 6AL/4V diamond-shaped downtube — effortless to setup and the perfect "no rattle" solution.
All frames are made in Chattanooga, TN, USA by Lynskey Performance. All frames come with a lifetime warranty.
Frame Purchase includes Rear Thru-Axle.
- Performance engineered diamond-shaped 6AL/4V tubeset for ultimate stiffness, stability, strength, and comfort
- Lynskey signature titanium tube within a tube internal cable routing system
- (1) top tube mount and (3) water bottle mounts
- Rack and fender mounts
- Tapered Headtube ensures precision handling when paired with Lynskey’s Carbon Gravel Fork
- 68mm English Threaded BSA Bottom Bracket Shell
- Wright style dropouts with replaceable aluminum hanger
- Conquer any mixed terrain with clearance for 700c x max 45mm
- Replaceable Derailleur Hanger: DW-200
Shimano GRX 815 Di2 1x11:
- Fork & Axle: Lynskey Pro GR Gravel Fork with 12mm Thru Axle
- Lever/Brakeset: Shimano ST-RX815 Di2 2x11 Speed STI Left Shifter Set (W/ BR-RX810 FM Caliper)
- Lever/Brakeset: Shimano ST-RX815 Di2 2x11 Speed STI Right Shifter Set (W/ BR-RX810 FM Caliper)
- Rear Brake Adaptor: Shimano R160 Disc Brake Adaptor 160mm Rotor Flat-Mount
- Brake Rotors: 160mm
- Rear Derailleur: Shimano GRX Di2 11 speed rear Derailleur - Long Cage for 1x
- Cassette: Shimano M8000 11 speed cassette 11-42t
- Crankset: Shimano GRX 810 1x11-SPD CRANKSET
- Chain: Shimano CN-HG701 QL Chain - 11 Speed
- Bottom Bracket: Shimano BBR60 68mm English Threaded Bottom Bracket
- Rear Axle: 12x142 Rear Axle
- Wheelset: Vision Team 30 Disc
- Tire: Kenda Alluvium Pro 120tpi 700x40c
- Tube: Presta 48mm Valve
- Handlebar: FSA Omega Compact Alloy Handlebar
- Bar Tape: Lynskey Bar Tape - Blk
- Stem: FSA Omega Stem +/- 6° Rise
- Headset: Cane Creek 40 IS 42/28.6- IS 52/40
- Compression Plug: FSA Compression Plug
- Headset Spacer: FSA Headset Spacer 10mm - Blk
- Headset Spacer: FSA Headset Spacer 5mm - Blk
- Seatpost: FSA SL-280 27.2 x 350mm x 20mm Setback Seatpost
- Saddle: Lynskey Pro Saddle - Blk
