The monocoque carbon frame houses the Bosch battery internally thanks to a cover also made of carbon fiber and incorporated into the diagonal tube, thus achieving a clean finish and maximum integration. In addition, it is possible to charge the battery without removing it from the frame.
Other characteristics of this bike is its versatility, because thanks to adjustable dropouts and a brake support independent of the rest of the structure, MMR have made the frame compatible with wheels of 27.5 1d, 27.5+ and 29 1d.
Bolt 10 Specifications:
- Battery - Bosch Power Tube 500
- Motor - Bosch Performance Line CX 25
- Frame - MMR Bolt - Unidireccional Carbon Monocoque. CC Frame, 1.5 HeadTube, Boost, TA 12mm, PressFit, Internal Cable Routing
- Fork - Rock Shox Reba RL 120 mm. Motion Control. SoloAir. Remote lock OneLoc. TA 15mm
- Steering - Ritchey Pro - Tapered
- Group - Shimano XT 11s
- Shifters - Shimano XT 11s
- Brakes - Shimano XT, discs RT-66 180/180
- Crank and Plate - MMR Boost - plate Bosch 15T with protector
- Cassette - Shimano SLX 11-46 11s
- Chain - Shimano HG601
- Wheels - XCR 9800+ Boost 15/12mm
- Tyres - Hutchinson Taipan plegable 27.5x2.8 Tubeless ready
- Handlebar - Ritchey WCS BB Black 720
- Seatpost - Ritchey WCS Zero BB Black 31.6x400
- Selle - Selle Italia XR
- Grips - MMR doble density
