The new Meta HT AM frame is truly adaptive. It has been designed to be ridden with several different configurations in mind:
- The frame allows tyres up to 27.5+ and 2.8'' for comfort and grip
- With 29'' wheels, a maximum tyre width of 60mm, the ETRTO value displayed on the tyre sidewall should not exceed 60-622. It optimises the ride and brings stability. You can find this value on all manufacturers websites
- The new Meta HT AM requires a fork height of between 555mm and 561mm. This usually corresponds to forks with 140mm to 150mm travel accommodating 29'' wheels
"All of these factors mean the new Meta HT AM has a changing personality all of its own meaning that it can go from an aggressive enduro hard tail to a comfortable trail bike. Each build will be unique whilst keeping the tempered character of a Commencal hard tail", concluded Commencal.
Meta HT AM Race Specifications:
- Frame - 2018 New Meta Ht Am Frame 650b, Al 6061 Triple Butted
- Fork - Rockshox Lyrik Rc, 160 Mm, Compression, Rebound, Boost
- Headset - Ride Alpha Zs44/Zs56
- Stem - New Ride Alpha, Aluminium 6061, 40 Mm, 31.8 Mm, 0° Angle
- Bar - Ride Alpha, Alloy 7075, Double Butted, 30 Mm Rise, 780 Mm, 31.8 Mm
- Grips - Ride Alpha, Ergonomic Grips, Plastic One Lock, Super Soft Compound
- Brakes - Sram Level, 200 Mm/180 Mm
- Shifters - Sram Nx, 1 X 11 Speed
- Front/Rear Mech - –/Sram Nx, 11 Speed
- Bottom Bracket - Sram Powerspline
- Crankset - Sram Nx X-Sync Steel, 32t, Boost 170 Mm On S/M, 175 Mm On L/Xl
- Chain - Sram Pc 1110
- Cassette - Sram Pg 1130, 11–42t
- Rims - Spank Oozy Trail 395+, 32 Holes, Tubeless Ready, 35 Mm Inner Width
- Hubs - Formula, 32 Holes, Sealed Bearings
- Spokes/Nipples - Pillar Spokes, Steel, 2 Mm Black/Brass Nipple 12 Mm Black Nylock
- Tyres - Maxxis High Roller Ii 650 X2 .8 Exo/Tr Front & Maxxis Rekon + 650 X 2.8 Exo/Tr Rear
- Seatpost - Ks Lev Integra, 31,6 Mm, 125 Mm Travel On S/M And 150 Mm On L/Xl, Southpaw Alloy Lever
- Saddle - Ride Alpha Superlight Foam, Crmo Rails
- Weight - 13.7 Kg
- Pedals Included - No
- Accessories - Chainstay Protector, Seatstay Protector
